Pressure Gauges



Perolo ND63 glycerin filled dial pressure gauges are designed to be fitted on tank containers, IBC’s or road tankers in order to measure and indicate existing pressure.











Features :


• Stainless steel body
• Stainless steel or brass internal parts depending on model
• Dual pressure scale, bar & psi
• Glycerin filled
• Bottom pressure connection
• Aluminum pointer



Specifications :


• Pressure range depending on application
• Nominal external diameter 63mm / 2.5”
• Accuracy class 2.5
• Pressure connection ¼” BSP


Options & Accessories :


• ¼” NPT pressure connection
• Other pressure scales



Part # Description PU IT Price/Item
7018060095 Full stainless steel, bottom connection, 0 to 6 bar (0 to 90 PSI) 1 MIS /each
7021020022 Stainless steel case brass, internals & bottom connection, 0 to 6 bar (0 to 90 PSI) 1 MIS /each
7021020024 Full stainless steel, bottom connection, 0 to 10 bar (0 to 140 PSI) 1 MIS /each
7021020029 Stainless steel case brass, internals & bottom connection, 0 to 10 bar (0 to 150 PSI) 1 MIS /each
7021020026 Stainless steel case brass, internals & bottom connection, 0 to 2,5 bar 1 MIS /each
7021020027 Stainless steel case brass, internals back connection, 0 to 40 bar (0 to 600 PSI) 1 MIS /each
7021020028 Full stainless steel connection, back connection,  0 to 40 bar (0 to 600 PSI) 1 MIS /each
7021020022 Alloy 1/4" BSP, Bottom Connection, ø 63mm, 0-6 bar SS Case 10 MIS /each
7021020029 Alloy 1/4" BSP, Bottom Connection, ø 63mm, 0-10 bar SS Case 10 MIS /each
7021020036 Alloy 1/4" BSP, Bottom Connection, ø 63mm, 0-40 bar SS Case 10 MIS /each
7021020037 SS 1/4" BSP, Bottom Connection, ø 63mm, 0-4 bar SS Case 5 MIS /each
7018060095 SS 1/4" BSP, Bottom Connection, ø 63mm, 0-6 bar SS Case 5 MIS /each
7021020035 SS 1/4" BSP, Bottom Connection, ø 63mm, 0-7 bar SS Case 5 MIS /each
7021020021 SS 1/4" BSP, Bottom Connection, ø 63mm, 0-10 bar SS Case 5 MIS /each
7021020038 SS 1/4" BSP, Bottom Connection, ø 63mm, 0-16 bar SS Case 5 MIS /each
7021020024 SS 1/4" BSP, Bottom Connection, ø 63mm, 0-40 bar SS Case 5 MIS /each
7021020039 SS 1/2" BSP, Bottom Connection, ø 100mm, 0-10 bar SS Case 5 MIS /each
7021020040 SS 1/4" NPT, Bottom Connection, ø 63mm, 0-7 bar SS Case 5 MIS /each
7021020041 SS 1/4" NPT, Bottom Connection, ø 63mm, 0-40 bar SS Case 5 MIS /each
7021020028 SS 1/4" NPT, Back Connection, ø 63mm, 0-40 bar SS Case 5 MIS /each
7021020042 SS 1/4" NPT, Bottom Connection, ø 100mm, 0-40 bar SS Case 5 MIS /each
7021020043 SS 1/4" NPT, Back Connection, ø 100mm, 0-40 bar SS Case 5 MIS /each


Dwg Pos: Drawing Position • PU: Packing Unit • IT: Item Type
