Airline ATCO™ 2" DN50 Full Bore Flanged
Perolo ATCO™ 2" Flanged ball valves are designed fo use on tank containers, road tankers, rail tank cars and static tanks to be used as an air line or for liquid transfer operation.
Other sizes available on request.
Features :
• 316L stainless steel construction
• PTFE and TFM gaskets and FEP/Silicone O’rings
• Double sealing
• Compact design
• Light weight: 12.5kg
• Easy maintenance
• Controlled tightening of the ball PTFE seal assembly
• Single seal design on both sides of the ball
• Compatible with standard interface for pneumatic actuator
• Clockwise or anti-clockwise operation available
• Working pressure: 16 bar
• Test pressure: 24 bar
• Design temperature: +190°C
• Pressure gauge connection
• Sealing
• HALAR® coating option available.
• Steam heating system option available.
• IMDG/ADR §6.7 conformity - E 14432 certified
